R46

Aluminum

Description

Slimline R46 is a sleek glass railing system by Artrail designed for modern architectural aesthetics. It offers exceptional technical prowess, including high wind load capacity and structural strength. Fabricated from super tough T6063 aluminum alloy, it ensures maximum security while maintaining a minimal, "floating" appearance. It is a preferred choice for high-end villas, bungalows, and commercial projects.

‍

‍

Key Features

  • System: Artrail Slimline R46 (AX-R46T) Railing System.
  • Application: Ideal for residential villas, bungalows, and commercial projects.
  • Structural Profile: Constructed from high-strength T6063 Aluminum alloy.
  • Visual Aesthetic: Features a minimal 25 mm top rail for a floating effect.
  • Safety: Engineered with a wind load capacity of 2.5 kpa.

‍

‍

Dimensions

  • Base Channel Height: 132 mm.
  • Base Profile Width: 46 mm.
  • Top Rail Width: 25 mm.
  • Total Railing Height: Customizable as per project requirements.
  • Glass Thickness: Supports 6+6 / 8+8 / 8 / 10 mm safety glass.

‍

Technical Specifications

  • Fabricator: Artrail.
  • Primary Material: Powder Coated 6063 Aluminum.
  • Finish: RAL standard finishes available.
  • Glazing: Laminated and Tempered Laminated safety glass.
  • Specialized Hardware: Includes a Level-IN glass leveling device for alignment.

‍

Technical Diagram
