PVD Mirror-Finish Stainless Steel Cladding

Specialised Metal Sheets

Description

PVD Mirror-Finish Stainless Steel Cladding is a premium architectural metal cladding system combining a highly polished stainless-steel surface with a durable decorative PVD colour coating. The mirror finish creates strong reflections of the surrounding architecture, light and landscape, while the metallic coating introduces colours such as gold, champagne, bronze, copper and other architectural tones.

The PVD process applies an extremely thin coating to the stainless-steel surface inside a vacuum chamber without obscuring the underlying polished finish. This makes the material particularly suitable for feature façades, entrances, columns, soffits, canopies and premium interior or exterior architectural elements where a distinctive reflective finish is required.

‍

Key Features

  • High-Reflective Mirror Finish: Creates a polished architectural surface with strong visual depth and reflections.
  • Premium Metallic Colours: Available in gold, champagne, bronze, copper and other PVD tones.
  • PVD Surface Technology: Colour is deposited as a thin surface coating while retaining the character of the stainless-steel finish.
  • Corrosion-Resistant Base Material: Stainless steel provides strong durability for architectural applications when the appropriate grade is selected.
  • Interior & Exterior Application: Suitable for façades, feature walls, columns, soffits, portals and canopies.
  • Excellent Formability: Stainless-steel sheets can be fabricated into folded panels, column wraps, fascia bands and custom architectural forms.
  • Distinctive Architectural Appearance: Ideal for landmark entrances, luxury retail, commercial developments and hospitality projects.
  • Multiple Surface Options: Can be combined with super-mirror, satin, hairline, brushed or textured finishes.
  • Low-Maintenance Surface: Smooth stainless-steel finishes are comparatively easy to maintain when correctly detailed.
  • Long-Term Finish Performance: PVD-treated stainless steel is used specifically to combine decorative appearance with the inherent durability of stainless steel.

    • ‍

    Dimensions

  • Sheet Width: Project specific
  • Sheet Length: Project specific
  • Sheet Thickness: According to selected grade and application
  • Panel Module Size: Customizable
  • Column Wrap Size: Project specific
  • Fold / Return Depth: According to fabrication requirement
  • Joint Width: Project specific
  • Maximum Panel Size: Subject to material thickness, wind load and structural design

    • ‍

    Technical Specifications

  • Product Type: Specialized Architectural Metal Cladding
  • Category: PVD Mirror-Finish Stainless Steel
  • Base Material: Stainless Steel
  • Typical Grades: AISI 304 / 316 depending on environment and application
  • Recommended Exterior Grade: Project-specific; 316L is widely used for architectural façades where increased corrosion resistance is required.
  • Surface Finish: Super Mirror / Mirror Polish
  • Colouring Process: PVD — Physical Vapour Deposition
  • Colour Options: Gold / Champagne / Bronze / Copper / Custom decorative finish
  • Configuration: Flat / folded / cassette / column wrap / custom fabricated panel
  • Installation: Mechanically fixed to compatible structural subframe
  • Support System: Aluminium / stainless steel / project-specific metal framework
  • Application: Façades, columns, soffits, entrances, canopies, fascia bands and feature surfaces
  • Fabrication: Cutting / bending / folding / forming as required
  • Panel Orientation: Horizontal / vertical / custom
  • Joint Arrangement: Open / sealed / project-specific
  • Wind Load: Subject to structural calculation
  • Exterior Suitability: Grade and coating system to be selected according to environmental exposure
  • Maintenance: Periodic cleaning according to surface finish and exposure conditions

    • ‍

    Technical Diagram
