Curtain Wall System

Curtain Wall

Description

Curtain Wall is the most versatile and widely used facade solution for low-to-mid-rise buildings. In this system, vertical mullions and horizontal transoms are installed piece-by-piece on-site, followed by the glass and pressure plates. This "stick-built" approach offers unmatched flexibility, allowing for precise on-site adjustments, complex faceted geometries, and seamless integration with building structures where tolerances vary.

Key Features

  • On-Site Flexibility: Piece-by-piece assembly allows for adjustments to civil tolerances in real-time.
  • Complex Geometries: Ideal for faceted, angular, or non-standard building shapes.
  • Slim Sightlines: Standard 50mm face width for a clean, uniform grid appearance.
  • Cost-Effective: Lower transport and handling costs compared to unitized systems.
  • Versatile Glazing: Compatible with a wide range of glass thicknesses and infill panels.
  • Structural Efficiency: Variable mullion depths available to suit specific wind load requirements.

    • ‍

    Dimensions

  • Face Width: 50mm (Standard).
  • Mullion Depth: 50mm – 250mm (Dependent on structural calculation).
  • Maximum Height: Limited only by structural support (typically floor-to-floor).

    • Technical Specifications

  • Glazing Method: Pressure plate with cover cap (Captive) or Structural Glazing (SG).
  • System Type: Stick System (Mullion & Transom).
  • Weather Performance: Continuous EPDM gaskets for water and air tightness.
  • Application: Low-to-mid-rise offices, retail frontages, and complex architectural features.

    • Technical Diagram
